Potential Cheap Video Card Upgrade

I’m popping back up to update the site and point to this interesting thread on the MacRumors forum about an option for an improved video card on the cheap for our G5s.

The Radeon X1900 Mac Edition was an expensive aftermarket card in its day and is near the top of the performance level for Power Mac G5s. The FX4500 is probably slightly better as a workstation card, but the X1900 holds its own against the 7800GT. If the method below works for you, it will save you a bundle of cash and give you another option for your aging PowerPC machine.

Read: https://forums.macrumors.com/threads/radeon-x1900-g5-mac-edition-cheap-n-easy-flashing-guide.2308103/

Let me know if you have any luck.

— Nathan

This Is the End: TenFourFox Development to Cease

Dear readers,

I was away enjoying the pristine beauty of western Maryland earlier this week when the news dropped from Cameron Kaiser that TenFourFox, the most important piece of software to keep our Power Mac G5s somewhat relevant in this modern era of complex interweb technology, is nearing the end of its active development.

First, this should be no surprise. Cameron has performed coding miracles figuring out ways to add features, squeeze better performance, and generally give us a secure and somewhat modern option for PowerPC Macs running 10.4 and 10.5 in recent years. There really are not any alternatives beyond jumping to Linux, which carries with it its own set of tradeoffs and challenges. There was always going to be an end to development for TenFourFox. It was just a matter of when and not if.

Plus, despite many PowerPC users upgrading to solid state drives, flashed graphics card, occasional CPU upgrades, and maxed out RAM, there isn’t any processing power to gain out of our aging and venerable Macs. The internet will continue to introduce new technologies and make life miserable. The modern web, even on a somewhat updated browser, will struggle on our older computers.

Cameron spells it out here:

Writing and maintaining a browser engine is fricking hard and everything moves far too quickly for a single developer now. However, JavaScript is what probably killed TenFourFox quickest. For better or for worse, web browsers’ primary role is no longer to view documents; it is to view applications that, by sheer coincidence, sometimes resemble documents. You can make workarounds to gracefully degrade where we have missing HTML or DOM features, but JavaScript is pretty much run or don’t, and more and more sites just plain collapse if any portion of it doesn’t.

I had the privilege of meeting Cameron back at vintage computer conference near Sunnyvale, CA several years back. It was awesome to thank him personally and find out how many other vintage projects he has going on. He’s a brilliant and kind guy, and we owe him our immense gratitude.

Of course, someone could come along and pick up on TenFourFox code and decide to tweak and add new features on their own. I’d be fully supportive of such an endeavor. Maybe PowerPC users could think about collectively pooling resources to hire 2-3 programmers to update javascript, add features, and optimize the browser. Possibilities remain.

In the meanwhile, does this mean our G5s are useless? Of course not! You can still do so many things on the modern web via your G5 – like chatting on IRC, sharing files, serving webpages, programming your dream projects, and browsing into the foreseeable future (but hopefully not accessing anything that needs to be sensitive/secure).

But it is ultimately another reminder that our Macs are getting older and older, and as Apple transitions full bore to Apple Silicon, we are not just one distant architecture behind but two. Yikes. Time flies. Enjoy your vintage Macs anyway.

— Nathan

G5 + Xbox 360

I missed this article from a couple of years ago which detail how to get the Xbox 360 SDK environment working on very specific PowerMac G5s. It’s a fun read, and I think it’s worthy of a look if you are curious of how PowerMac G5s influenced console gaming history. And kind of makes me want to play some Xbox games on my old G5.

The equipment needed to get the very finicky Xbox 360 SDK image to work though is something:

• A Power Mac G5 with two 2 GHz CPUs (only this frequency). You need a 2003 or 2004 version, but not a 2005 model, nor a PCI-Express model (with a dual core processor). If your Mac has four slots for RAM (not eight), it’s not good.
• At least 512 MB of RAM. Normally, it is not a problem.
• A hard disk of 160 GB, a priori necessarily a Seagate ST3160023AS. This is the original model. I tried with an SSD without success, and my Mac no longer had the original hard drive. It is easily found on eBay for a few euros with the right reference. It may work with others, but I did not succeed.
• An IDE optical drive, mandatory. This should not be a problem: Power Macs have one.
• An Intel network card if you want to connect the machine. It requires an Intel Pro100+ PCI, reference 741462-010 (the one provided by Microsoft) or 741462-010. It’s easy to find it on eBay.
• An Xbox controller (original) with a USB adapter or a wired Xbox 360 controller. Careful, not a “Play & Charge” version.
• An ATi Radeon X800 XT 256 MB with two DVI outputs (that’s important) and a Mac BIOS. This is the complicated part, let’s detail it.

If you happen to check all of those boxes off the list and have an afternoon to kill, let us know how it goes, alright?

Read the whole article at Journal Dulapin.

The Mars 2020 Rover Runs on PowerPC

Congratulations to NASA for landing its latest Rover successfully on the surface of Mars.

I found this bit of info on Twitter today, but the Rover runs on a 200 MHz PowerPC CPU. I found it fascinating for those of us who still get a bit of use out of our old PowerPC tech. So does NASA, apparently.

Read more here: https://mars.nasa.gov/mars2020/spacecraft/rover/brains/

Into the Void: Void Linux PPC Review

ArcticFox in Void Linux PPC

As our Power Mac G5s and other PowerPC Macs age rapidly, our machines are trapped in time. We can count on one hand, maybe two, the amount of software packages that are still being actively maintained and updated for our hardware, including the valuable TenFourFox. Of course, it’s not the end of the world to use dated but perfectly functional software to write our papers, design websites, create graphics, and so on, but getting our PowerPC Macs online in a secure and functional way with the complexity of the modern web gets trickier each year.

Don’t forget that Leopard (Mac OS X 10.5) received its last security update… a long time ago.

Wouldn’t it be nice to tinker with modern up to date software in a more secure operating system?

Say hello to Void Linux for PPC, pictured above running on my Mac Mini G4.

What is Void Linux?

Void Linux PPC is an up to date, community-led Linux-based OS. The distribution is not official but driven by a dedicated group of developers using Void Linux as its base. The main target and energy around the distribution focuses on newer PowerPC machines, including Raptor’s Blackbird line of motherboards and machines, but our older PowerPC Macs are supported, including install instructions and well-organized tips and tricks to get started.

In the larger picture, Void Linux stands out due to its own package management system called xbps, and per the main distribution website, it emphasizes stability over a rolling release. However, packages are frequently updated. For example, when the newest XFCE4 desktop environment was released on December 22, I was able to update to the latest and greatest XFCE4 as of January 1. The most recent kernel version is 5.9.16_1, which is so cool to run recent Linux kernels on such old hardware.

As I highlighted in my brief look at MacBuntu several weeks back, you can make a strong argument that older machines should stick with software from its period just for speed alone, but it is cool to be able to use more recent Linux kernels, desktop environments, and other open source applications on your ancient Mac. Performance, while not blazing fast, is quite solid.

Another area that makes Void Linux unique is that it supports both musl and gnu libc implementations of the standard shared Linux library. These are the libraries that serve as the common foundation for many core Linux software packages across various distributions. MUSL is intriguing for PowerPC users because it is newer and “cleaner”, but gnu libc is more popular and benefits from years of optimization. There is one other added bonus – libc works better with some hardware drivers, especially proprietary gpu drivers. I ended up going with the libc version as it avoids a couple of GPU bugs on my ancient Radeon 9200 GPU in the Mac Mini. You can read about GPU compatibility with Void Linux PPC on this handy chart.

The PowerPC distribution also has a quite thorough number of software packages available for install, though it appears that the number fluctuates as some package updates require fixes to be able to build properly on our old Macs. I know there were a few software packages I couldn’t find during my test run, but most things I needed are available in one form or another. You can poke through the list of available packages here.

What is the install like?

Install was relatively straightforward. Using a USB flash drive, as my old DVD drive in the G4 died years ago, I booted into a basic Void Linux PPC environment, typed in void-installer, and made my way through the process. The website offers an excellent step by step tutorial, including tips to make sure your hard drive is properly formatted, even in the case where you might want to still be able to boot into Mac OS X. My first major issue during installation was getting my internal SSD to partition and format. No matter what I tried, my partition map came out all wrong. I ended up flashing the install image to the USB drive a second time. For whatever reason, it worked. No idea why. (Hint: Be ready for these kinds of strange experiences with Linux from time to time.)

After the install, you are greeted with a login prompt, which is perfect if you want to run your Mac Mini as a server. Then you can begin updating the package manager and core packages using xbps-install -Su and building the environment you are comfortable with. Various desktop environments and window managers are available. I prefer XFCE4 for its flexibility, style, and ability to get out of the way. Plus, it’s pretty light. There are lighter and beefier options available though.

The install was the first part of the process – what can be time consuming and head scratching is that next step of hunting for software packages that will fill your needs. I have experience with other distributions, so it was a little frustrating to have to hunt for the right package name since it could be named differently in Void Linux. Nonetheless, with patience and a few google searches, I was able to begin building the environment you see above. Sure, there were bugs along the way, like how sudo xbps-install xfce4 didn’t include all the packages I really needed. Luckily, fellow users in the voidlinuxppc channel on Freenode were able to help. Great people!

ReText, XFCE Terminal, and About XFCE4 in Void Linux PPC

How is it on the internet?

Unfortunately, web browsing is a slight challenge.

One webkit-based browser available on Void Linux PPC is Epiphany, though you will need to type in an EXPORT command listed in the Frequently Asked Questions page to make sure it renders webpages the correct way. For me, it lags and wasn’t very reliable.

I was able to install the ArcticFox PowerPC Debian package with minimal fuss, and it works great. However, Arctic Fox is an older build.

Of course, you can also use some command line web browsers as a backup plan.

As some good news, I recommend following the work of Jake Hamby who is seeking to build more recent versions of FireFox for PowerPC Linux. May his efforts bear fruit soon!

Beyond web browsing, you can easily ssh into your favorite servers, download multiple IRC clients, and use your Mac as a server. I am accessing it over x11vnc too, and the performance is decent on my personal network. The nice thing is that I know security updates are constantly on the way for both internet facing applications as well as the core software in the distribution. That’s really cool.

Could it be a daily driver?

Sure. Some apps are just as speedy and functional, if not as pretty, as many Mac OS X Leopard variants. For example, I’ve switched from XChat to Quassel for my preferred IRC client. Both options work great. LibreOffice should be available, though I’ve installed AbiWord for now since it is lighter and I’ve never been a fan of LibreOffice. Another app that seems promising for coding and text work is Geany. A workable Markdown editor is ReText, though I wish some newer and better looking options were available.

And really, I’ve just started scratching the surface of resources of available packages for install.

For developers on these old machines, you’ve got a variety of options to tinker with, including Python3.

Best of all, you can configure Void Linux PPC to your liking. XFCE4 in particular can be made to look very Mac-like, and there are a plethora of themes available to give you dark, vintage, or minimal styles.

But what are its downsides?

In addition to some general frustrations and a learning curve that could scare off some users, Void Linux PPC has the same challenges that all Linux distributions face – hit or miss hardware support, lack of polish, software that can be functional but look like crap, lots of error messages that require googling to figure out how to address, and a general non-user friendliness.

You will definitely miss some of your favorite software packages from the Mac world.

Mac OS X is simply beautiful and optimized for our Macs. Going to Linux, where most of the desktop environment has to run without any hardware optimization, is jarring. I think Linux could be better optimized, but who is going to hire developers to target hardware as old as ours? There are plenty of cases where new PC hardware doesn’t run well in Linux. It’s simply the nature of open source software. People spend time focusing on what they are passionate about, hardware support requires buy in from hardware manufacturers, and these old PowerPC machines are only on a few people’s radars anymore.

Case in point, I spent a few hours working to get a compositor going with XFCE4. The default compositor should be turned off immediately for a little better performance, relying on software rendering rather than hardware rendering. Another option is the venerable compiz compositor, but though it is available in the repositories, enabling it means an instant freeze and hardware crash. It would be nice to have even a minimal compositor to get better performance out of window draws and refreshes for a more pleasant desktop experience. (Maybe a dash of transparency wouldn’t hurt.)

The other challenge is your need to search Google frequently or reach out for help to sort through bugs that really shouldn’t exist. On one hand, some of these bugs are ignorable. For example, I received a constant PolicyKit error when launching XFCE4 for a while, until I found the other dependencies XFCE4 was looking for, including a window manager to load on launch. The error didn’t affect the operation of XFCE in a show stopper way – just annoying. XFCE’s included Power Manager didn’t work as well, exiting with an error, until I installed some other missing components. Fixing these issues wasn’t intuitive, since the PolicyKit error or PowerManager error tell you nothing about next steps.

Part of this comes from the design of Linux to have the ability to install just what you need. For a server or a secure environment, that makes sense, but for desktop environments, why not install every component, even alternative components like themes, to save the user time and insure a smooth experience? Just because the component is installed, it doesn’t mean the user will have to configure it or even run it. And while I can hear the argument that learning to tinker and solve problems is a win, it’s not really. I don’t think I will have any other moment in my life when I need to know how to fix PolicyKit errors in Linux.

Just be ready when entering the world of Linux to know that there will be issues, and you will need to take some time to get the optimal environment/setup that works for you. Do your best not to give up, and keep in mind you can always start over.

Conclusion

Ultimately, I like Void Linux PPC and recommend it for PowerPC users who want to move to an operating system that is still getting software updates. Since I already have Leopard going on my Power Mac G5, I’m excited to continue to tinker with my Mac Mini G4 and see what I can do with it. I found the documentation on the website as well as the MacRumors thread and VoidLinuxPPC IRC channel helpful resources to learn more and get feedback. That’s a good sign.

There are challenges – you will need to be prepared to roll up your sleeves and do some proactive tinkering to get things fully working. Linux may not be for you, and that’s okay. But it is a great option to keep our PowerPC machines rolling into the void of uncertainty that is 2021 and beyond.

— Nathan
